Barix Instreamer ICE IP Audio Encoder/Server

 375,00

Barix Instreamer ICE IP Audio Encoder/Server

The Instreamer ICE encodes analog audio into MP3 or AAC for streaming to Icecast or Shoutcast internet radio services. It includes a built-in Icecast server for up to 100 listeners.

Description

Barix Instreamer ICE IP Audio Encoder/Server

The Instreamer ICE encodes analog audio into MP3 or AAC for streaming to an Icecast or  Shoutcast internet radio streaming service in the cloud. The Instreamer ICE also has an Icecast server built in and is able to feed up to 50 web radio listeners directly without the requirement to  subscribe to an internet radio service provider.

Applications

  • Live IP Audio Encoder for Streaming Applications
    Shoutcast/Icecast Source Encoder

Features

  • MP3 and AAC+ encoding
  • Stream authentication
  • Icecast source mode
  • Stream Relay
  • Streams to Icecast internet radio service
  • Integrated Icecast streams to 100 simultaneous listeners without radio service
  • Line input (stereo)
  • Supply voltage 5VDC

Power Supply Input
• External power adaptor, 100-240VAC, 10W
• Male connector: 5,5 x 2,1 mm

1 Ethernet Interfaces
• RJ45 10/100 auto detect, IPv4, IPv6

Audio Input
• Stereo RCA / cinch connectors

Audio formats
• MP3, AAC mono and stereo
• Sample rates 22.05/24/32/44.1/48Khz

Headphone output
• Female Jack 3.5 mm
USB
• Double USB connector type A female
(for future use)

RS-232
• For meta data contribution

Icecast
• Integrated Icecast server:
supports up to 50 subscribers
• Source to external Icecast server

HW/SW environment
• Barix IPAM400
• Linux with dual boot recovery and remote  firmware update capability

User Interface
• Web interface for control, status and  configuration
• HW reset button, LEDs for status

Case & Weight
• Aluminum
• 108x38x78.7mm (4.25×1.5×3.1 inch)
• Weight 250g
MTBF
• >199’951 h / > 22 years
Warranty
• Warranty: two years

Discription

Barix Instreamer ICE IP Audio Encoder/Server

The Instreamer ICE encodes analog audio into MP3 or AAC for streaming to an Icecast or  Shoutcast internet radio streaming service in the cloud. The Instreamer ICE also has an Icecast server built in and is able to feed up to 50 web radio listeners directly without the requirement to  subscribe to an internet radio service provider.

Applications

  • Live IP Audio Encoder for Streaming Applications
    Shoutcast/Icecast Source Encoder

Features

  • MP3 and AAC+ encoding
  • Stream authentication
  • Icecast source mode
  • Stream Relay
  • Streams to Icecast internet radio service
  • Integrated Icecast streams to 100 simultaneous listeners without radio service
  • Line input (stereo)
  • Supply voltage 5VDC
Specifications

Power Supply Input
• External power adaptor, 100-240VAC, 10W
• Male connector: 5,5 x 2,1 mm

1 Ethernet Interfaces
• RJ45 10/100 auto detect, IPv4, IPv6

Audio Input
• Stereo RCA / cinch connectors

Audio formats
• MP3, AAC mono and stereo
• Sample rates 22.05/24/32/44.1/48Khz

Headphone output
• Female Jack 3.5 mm
USB
• Double USB connector type A female
(for future use)

RS-232
• For meta data contribution

Icecast
• Integrated Icecast server:
supports up to 50 subscribers
• Source to external Icecast server

HW/SW environment
• Barix IPAM400
• Linux with dual boot recovery and remote  firmware update capability

User Interface
• Web interface for control, status and  configuration
• HW reset button, LEDs for status

Case & Weight
• Aluminum
• 108x38x78.7mm (4.25×1.5×3.1 inch)
• Weight 250g
MTBF
• >199’951 h / > 22 years
Warranty
• Warranty: two years

Additional information

Weight 1 kg
Dimensions 25 × 15 × 7 cm

Brand

Barix
