Description
Tascam SS-R250N Networkable Solid-State Audio Recorder
Discover the versatility of the Tascam SS-R250N Solid-State Audio Recorder.
With the Tascam SS-R250N you get an extremely versatile audio device. This recorder supports recording in stunning 24-bit quality up to 96 kHz and offers a wide range of recording media. But that’s not all, the impressive connectivity options make this recorder an essential tool for broadcast professionals and audio editors.
Ease of connection and control
Featuring traditional XLR connections and support for AES/EBU multi-channel audio, RCA and S/PDIF, the SS-R250N offers numerous options to integrate devices and create a seamless workflow. With the ability to operate the player via a separately available footswitch or remote, you always have full control over your recording sessions. Additionally, built-in networking functionality makes it easy to stream audio to other locations or manage automatic upload and download processes via FTP.
Reliability above all
At Tascam, reliability comes first. The SS-R250N is designed with the safety and security of your precious audio data in mind. Password protection prevents unauthorized access to your files, giving you peace of mind when sharing and distributing. Furthermore, the pre-recording function ensures that no precious moment is lost, while the ability to simultaneously record onto two memory cards provides extra peace of mind.
Flexible storage options and useful features
With support for both SD cards and USB media, the SS-R250N offers maximum flexibility when storing your audio files. Whether you choose SD, SDHC or SDXC cards, with a maximum capacity of 128 gigabytes, or USB memory, you always have enough space for all your recordings. Thanks to features such as highlighting, Auto Cue and Auto Ready, managing and retrieving specific passages becomes a breeze. In addition, the Auto Level Control function ensures that your recordings are always clear and free of clipping.
In short, with the Tascam SS-R250N Solid-State Audio Recorder you are assured of high-quality performance, maximum reliability and ultimate control over your audio recordings. Discover the possibilities today and take your sound production to a higher level.
General features
- Records to and plays from USB flash memory (up to 64 GB), SD/SDHC/SDXC cards (up to 128 GB)
- Supports recording and playback of high-resolution files up to 96 kHz / 24 bit
Network/control capabilities
- FTP client function enables automatic uploading of recorded files or downloading audio files from the server
- With event lists for recording, playback, download and other functions, the unit can be operated automatically based on the time set
- Time synchronisation via SNTP client enables event management with high accuracy
- iOS/Android control app allows transport operations and remote control of various settings
- Optional IF-DA2 interface card supports Dante two-channel input and output
- Serial and parallel ports
- RC-SS150 flash start controller with a colour LCD screen available as an option
- Tascam RC-3F footswitch or RC-20 remote control can be connected
Recording capabilities
- Dual SD memory card slot permits mirror and relay recording
- Marks can be set automatically when an error occurs or the input overloads
- The pre-recording function prevents any missing part at the beginning of your recordings
- Auto track function automatically trims audio material to tracks
- Compressor and limiter can help to improve the recording quality
- Auto level control available to automatically adjust the input level for recording
- Recording can be started as soon as the unit is turned on (Power-on recording function)
- Direct recording enables a recording to start without switching to record ready first
- XLR input connectors for microphones with phantom power supply (can also be used with line sources)
- RCA input connectors for consumer-level sources
- AES/EBU digital input (XLR)
- SPDIF coaxial input (RCA)
Playback functions
- Call function that saves the position where your last playback starts
- Ducking function automatically reduces the playback level while the input level rises and vice versa
- Incremental play (skip to each next track by pressing the PLAY button)
- Auto Cue locates the first sound in a track when in playback standby
- Auto Ready allows playback standby before the next track begins
- Pitch control and key control function for speed and key adjustments
- Playback modes such as Program, Random, and Single
- Repeat function (all tracks, A–B section)
- Monaural mix playback function
- Marks can be set at any position
- EOM (End of message) can notify the user before the track ends
Other features
- Sampling rate converter for inputs and outputs
- Link playback function allows two units to be operated in parallel
- Automatic file closing to avoid data loss if there is a sudden power loss during recording
- User presets: Up to three sets of settings can be stored to quickly switch input and output, sampling rate and other functions
- 1U rack-mount size
Specifications
| General | |
|---|---|
| Recording media | SD cards (512 MB – 2 GB) SDHC cards (4–32 GB) SDXC cards (64–128 GB) USB flash drives (512 MB – 64 GB) CD-R/CD-RW |
| Recording and playback file formats | MP3: 44.1/48 kHz, 64/128/192/256/320 Kbit/s WAV: 44.1/48/96 kHz, 16/24 bits CD-DA |
| Number of channels | 2 channels (stereo) 1 channel (mono) |
| Analogue audio inputs and outputs | |
|---|---|
| Analogue input (unbalanced) | RCA pin jacks |
| Rated input level | –10 dBV (0.316 Vrms) |
| Maximum input level | +6 dBV (2.0 Vrms) |
| Input impedance | 10 kΩ or higher |
| Analogue input (balanced) | XLR-3-31 (1: GND, 2: HOT, 3: COLD) |
| When used as line input | |
| Nominal input level | +4 dBu (1.23 Vrms, when Ref.Level set to other than −9 dBFS) +6 dBu (1.55 Vrms, when Ref. Level set to −9 dBFS) |
| Maximum input level (switchable) | +15 dBu (4.36 Vrms, Ref. Level: −9 dBFS) +18 dBu (6.16 Vrms, Ref. Level: −14 dBFS) +20 dBu (7.75 Vrms, Ref. Level: −16 dBFS) +22 dBu (9.76 Vrms, Ref. Level: −18 dBFS) +24 dBu (12.28 Vrms, Ref. Level: −20 dBFS) |
| Input impedance | 10 kΩ or higher |
| When used as mic input (phantom power supported) | |
| Maximum input level | +4 dBu (1.23 Vrms) |
| Minimum input level | –70 dBu (245 μVrms) or higher |
| Input impedance | 2.2 kΩ or higher |
| Analogue output (unbalanced) | RCA pin jacks |
| Rated output level | –10 dBV (0.316 Vrms) |
| Maximum output level | +6 dBV (2.0 Vrms) |
| Output impedance | 200 Ω |
| Analogue output (balanced) | XLR-3-32 (1: GND, 2: HOT, 3: COLD) |
| Nominal output level | +4 dBu (1.23 Vrms, when Ref.Level set to other than −9 dBFS) +6 dBu (1.55 Vrms, when Ref. Level set to −9 dBFS) |
| Maximum output level (switchable) | +15 dBu (4.36 Vrms, Ref.Level: −9 dBFS) +18 dBu (6.16 Vrms, Ref.Level: −14 dBFS) +20 dBu (7.75 Vrms, Ref.Level: −16 dBFS) +22 dBu (9.76 Vrms, Ref. Level: −18 dBFS) +24 dBu (12.28 Vrms, Ref.Level: −20 dBFS) |
| Output impedance | 200 Ω |
| Phones output | 6.3-mm standard stereo jack |
| Maximum output power | 45 mW + 45 mW or higher (THD+N 0.1% or less, into 32 Ω load) |
| Digital audio inputs and outputs | |
|---|---|
| Digital input (AES/EBU) | XLR-3-31 |
| Input impedance | 110 Ω |
| Format | AES3-2003 / IEC60958-4 (AES/EBU) |
| Supported sampling frequencies | 44.1 kHz, 48 kHz, 96 kHz When SRC ON, 32–192 kHz can be received |
| Digital input (SPDIF) | RCA pin jack |
| Format | IEC60958-3 |
| Supported sampling frequencies | 44.1 kHz, 48 kHz, 96 kHz When SRC ON, 32–192 kHz can be received |
| Digital output (AES/EBU) | XLR-3-32 |
| Output impedance | 110 Ω |
| Format | AES3-2003 / IEC60958-4 (AES/EBU) |
| Supported sampling frequencies | 44.1 kHz, 48 kHz, 96 kHz |
| Digital output (SPDIF) | RCA pin jack |
| Format | IEC60958-3 (SPDIF) |
| Other inputs and outputs | |
|---|---|
| Remote jack | 2.5-mm TRS jack (for Tascam RC-3F or RC-20, sold separately) |
| USB port | 4-pin USB, A-type |
| Protocol | USB 2.0 High Speed (480 Mbit/s) |
| Serial port (RS-232C) | D-sub 9-pin |
| Parallel port | D-sub 25-pin |
| Maximum input voltage | +5.5 V |
| High-level minimum input voltage | +2.31 V |
| Low-level maximum input voltage | +0.99 V |
| Output format | Open collector (10 Ω output impedance, 20 V withstand voltage, 35 mA maximum) |
| Low-level maximum output voltage | 0.5 V |
| 5 V power supply maximum supplied current | 100 mA |
| Network connector (Ethernet) | RJ45 |
| Compatible standard | 100BASE-TX |
| Audio performance | |
|---|---|
| Frequency response (LINE IN or MIC IN to LINE OUT) | 20 Hz – 20 kHz, ±0.5 dB (Fs = 44.1/48 kHz, JEITA) 20 Hz – 40 kHz, +0.5/-3 dB (Fs = 96 kHz, JEITA) |
| Distortion | 0.002 % or less (LINE IN to LINE OUT, Ref. Level: −16 dBFS, Fs = 44.1/48/96 kHz, JEITA) |
| S/N ratio | 106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) |
| Dynamic range | 106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) |
| Crosstalk | 100 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) |
| Equivalent input noise (EIN) | −125 dBu or less (150 Ω, 20 kHz LPF, A-weighted) |
| Power supply and other specifications | |
|---|---|
| Mains power | AC 100–240 V, 50-60 Hz |
| Power consumption | 20 W |
| Dimensions (W × H × D) | 483 mm × 45 mm × 301 mm |
| Weight | 3.2 kg |
| Permissible operating temperature range | 5–35 °C |
- Description
-
Tascam SS-R250N Networkable Solid-State Audio Recorder
Discover the versatility of the Tascam SS-R250N Solid-State Audio Recorder.
With the Tascam SS-R250N you get an extremely versatile audio device. This recorder supports recording in stunning 24-bit quality up to 96 kHz and offers a wide range of recording media. But that’s not all, the impressive connectivity options make this recorder an essential tool for broadcast professionals and audio editors.
Ease of connection and control
Featuring traditional XLR connections and support for AES/EBU multi-channel audio, RCA and S/PDIF, the SS-R250N offers numerous options to integrate devices and create a seamless workflow. With the ability to operate the player via a separately available footswitch or remote, you always have full control over your recording sessions. Additionally, built-in networking functionality makes it easy to stream audio to other locations or manage automatic upload and download processes via FTP.
Reliability above all
At Tascam, reliability comes first. The SS-R250N is designed with the safety and security of your precious audio data in mind. Password protection prevents unauthorized access to your files, giving you peace of mind when sharing and distributing. Furthermore, the pre-recording function ensures that no precious moment is lost, while the ability to simultaneously record onto two memory cards provides extra peace of mind.
Flexible storage options and useful features
With support for both SD cards and USB media, the SS-R250N offers maximum flexibility when storing your audio files. Whether you choose SD, SDHC or SDXC cards, with a maximum capacity of 128 gigabytes, or USB memory, you always have enough space for all your recordings. Thanks to features such as highlighting, Auto Cue and Auto Ready, managing and retrieving specific passages becomes a breeze. In addition, the Auto Level Control function ensures that your recordings are always clear and free of clipping.
In short, with the Tascam SS-R250N Solid-State Audio Recorder you are assured of high-quality performance, maximum reliability and ultimate control over your audio recordings. Discover the possibilities today and take your sound production to a higher level.
General features
- Records to and plays from USB flash memory (up to 64 GB), SD/SDHC/SDXC cards (up to 128 GB)
- Supports recording and playback of high-resolution files up to 96 kHz / 24 bit
Network/control capabilities
- FTP client function enables automatic uploading of recorded files or downloading audio files from the server
- With event lists for recording, playback, download and other functions, the unit can be operated automatically based on the time set
- Time synchronisation via SNTP client enables event management with high accuracy
- iOS/Android control app allows transport operations and remote control of various settings
- Optional IF-DA2 interface card supports Dante two-channel input and output
- Serial and parallel ports
- RC-SS150 flash start controller with a colour LCD screen available as an option
- Tascam RC-3F footswitch or RC-20 remote control can be connected
Recording capabilities
- Dual SD memory card slot permits mirror and relay recording
- Marks can be set automatically when an error occurs or the input overloads
- The pre-recording function prevents any missing part at the beginning of your recordings
- Auto track function automatically trims audio material to tracks
- Compressor and limiter can help to improve the recording quality
- Auto level control available to automatically adjust the input level for recording
- Recording can be started as soon as the unit is turned on (Power-on recording function)
- Direct recording enables a recording to start without switching to record ready first
- XLR input connectors for microphones with phantom power supply (can also be used with line sources)
- RCA input connectors for consumer-level sources
- AES/EBU digital input (XLR)
- SPDIF coaxial input (RCA)
Playback functions
- Call function that saves the position where your last playback starts
- Ducking function automatically reduces the playback level while the input level rises and vice versa
- Incremental play (skip to each next track by pressing the PLAY button)
- Auto Cue locates the first sound in a track when in playback standby
- Auto Ready allows playback standby before the next track begins
- Pitch control and key control function for speed and key adjustments
- Playback modes such as Program, Random, and Single
- Repeat function (all tracks, A–B section)
- Monaural mix playback function
- Marks can be set at any position
- EOM (End of message) can notify the user before the track ends
Other features
- Sampling rate converter for inputs and outputs
- Link playback function allows two units to be operated in parallel
- Automatic file closing to avoid data loss if there is a sudden power loss during recording
- User presets: Up to three sets of settings can be stored to quickly switch input and output, sampling rate and other functions
- 1U rack-mount size
- Specifications
-
Specifications
General Recording media SD cards (512 MB – 2 GB)
SDHC cards (4–32 GB)
SDXC cards (64–128 GB)
USB flash drives (512 MB – 64 GB)
CD-R/CD-RWRecording and playback file formats MP3: 44.1/48 kHz, 64/128/192/256/320 Kbit/s
WAV: 44.1/48/96 kHz, 16/24 bits
CD-DANumber of channels 2 channels (stereo)
1 channel (mono)Analogue audio inputs and outputs Analogue input (unbalanced) RCA pin jacks Rated input level –10 dBV (0.316 Vrms) Maximum input level +6 dBV (2.0 Vrms) Input impedance 10 kΩ or higher Analogue input (balanced) XLR-3-31 (1: GND, 2: HOT, 3: COLD) When used as line input Nominal input level +4 dBu (1.23 Vrms, when Ref.Level set to other than −9 dBFS)
+6 dBu (1.55 Vrms, when Ref. Level set to −9 dBFS)Maximum input level (switchable) +15 dBu (4.36 Vrms, Ref. Level: −9 dBFS)
+18 dBu (6.16 Vrms, Ref. Level: −14 dBFS)
+20 dBu (7.75 Vrms, Ref. Level: −16 dBFS)
+22 dBu (9.76 Vrms, Ref. Level: −18 dBFS)
+24 dBu (12.28 Vrms, Ref. Level: −20 dBFS)Input impedance 10 kΩ or higher When used as mic input (phantom power supported) Maximum input level +4 dBu (1.23 Vrms) Minimum input level –70 dBu (245 μVrms) or higher Input impedance 2.2 kΩ or higher Analogue output (unbalanced) RCA pin jacks Rated output level –10 dBV (0.316 Vrms) Maximum output level +6 dBV (2.0 Vrms) Output impedance 200 Ω Analogue output (balanced) XLR-3-32 (1: GND, 2: HOT, 3: COLD) Nominal output level +4 dBu (1.23 Vrms, when Ref.Level set to other than −9 dBFS)
+6 dBu (1.55 Vrms, when Ref. Level set to −9 dBFS)Maximum output level (switchable) +15 dBu (4.36 Vrms, Ref.Level: −9 dBFS)
+18 dBu (6.16 Vrms, Ref.Level: −14 dBFS)
+20 dBu (7.75 Vrms, Ref.Level: −16 dBFS)
+22 dBu (9.76 Vrms, Ref. Level: −18 dBFS)
+24 dBu (12.28 Vrms, Ref.Level: −20 dBFS)Output impedance 200 Ω Phones output 6.3-mm standard stereo jack Maximum output power 45 mW + 45 mW or higher (THD+N 0.1% or less, into 32 Ω load) Digital audio inputs and outputs Digital input (AES/EBU) XLR-3-31 Input impedance 110 Ω Format AES3-2003 / IEC60958-4 (AES/EBU) Supported sampling frequencies 44.1 kHz, 48 kHz, 96 kHz
When SRC ON, 32–192 kHz can be receivedDigital input (SPDIF) RCA pin jack Format IEC60958-3 Supported sampling frequencies 44.1 kHz, 48 kHz, 96 kHz
When SRC ON, 32–192 kHz can be receivedDigital output (AES/EBU) XLR-3-32 Output impedance 110 Ω Format AES3-2003 / IEC60958-4 (AES/EBU) Supported sampling frequencies 44.1 kHz, 48 kHz, 96 kHz Digital output (SPDIF) RCA pin jack Format IEC60958-3 (SPDIF) Other inputs and outputs Remote jack 2.5-mm TRS jack (for Tascam RC-3F or RC-20, sold separately) USB port 4-pin USB, A-type Protocol USB 2.0 High Speed (480 Mbit/s) Serial port (RS-232C) D-sub 9-pin Parallel port D-sub 25-pin Maximum input voltage +5.5 V High-level minimum input voltage +2.31 V Low-level maximum input voltage +0.99 V Output format Open collector (10 Ω output impedance, 20 V withstand voltage, 35 mA maximum) Low-level maximum output voltage 0.5 V 5 V power supply maximum supplied current 100 mA Network connector (Ethernet) RJ45 Compatible standard 100BASE-TX Audio performance Frequency response (LINE IN or MIC IN to LINE OUT) 20 Hz – 20 kHz, ±0.5 dB (Fs = 44.1/48 kHz, JEITA)
20 Hz – 40 kHz, +0.5/-3 dB (Fs = 96 kHz, JEITA)Distortion 0.002 % or less (LINE IN to LINE OUT, Ref. Level: −16 dBFS, Fs = 44.1/48/96 kHz, JEITA) S/N ratio 106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) Dynamic range 106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) Crosstalk 100 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA) Equivalent input noise (EIN) −125 dBu or less (150 Ω, 20 kHz LPF, A-weighted) Power supply and other specifications Mains power AC 100–240 V, 50-60 Hz Power consumption 20 W Dimensions (W × H × D) 483 mm × 45 mm × 301 mm Weight 3.2 kg Permissible operating temperature range 5–35 °C - Video
-
